Using NixOS

CIFS Mounts

One very useful module I created was automatic CIFS volume mounting:

{
  user,
  lib,
  ...
}: let
  paths = [
    "/Users/${user}/mnt/server/mount"
    ...

  ];
in {
  system.activationScripts.mountsPermissions.text = ''
    echo "Setting up mount paths..." >&2
    for path in ${lib.concatStringsSep " " paths}; do
      if [ ! -d "$path" ]; then
        mkdir -p "$path"
        chown ${user}:staff "$path"
        chmod 755 "$path"
      fi
    done
  '';

  launchd.user.agents.mount_server.serviceConfig = {
    Label = "mount.server";
    RunAtLoad = true;
    ProgramArguments = [
      "/sbin/mount_smbfs"
      "-f"
      "0775"
      "-d"
      "0775"
      "smb://user:password@server/mount"
      "/Users/${user}/mnt/server/mount"
    ];
    StandardErrorPath = "/tmp/mount_server.err.log";
    StandardOutPath = "/tmp/mount_server.out.log";
  };

  ...
}

With that, I had all my mounts already connected after login. The drawback, as you immediately see, is that the username and password are part of the config - which is the reason I have never published my own publicly. This ultimately leads to secrets management, but more on that later.

Quickshell and Caelestia

Initially I was running my Hyprland config based on JaKooLit’s Hyprland-Dots but very soon while browsing Reddit I discovered Caelestia Shell :

[Hyprland] I <3 Quickshell
by u/Rexcrazy804 in unixporn

I was instantly struck by its simplicity and fluidity and I decided to switch to it. The only thing I did not like was the bar on the left, rather than the usual top or bottom, so I forked and continue to maintain my own version with the bar moved to the top. Caelestia has a flake.nix, so to use it on NixOS you just need to add it as an input:

inputs = {
    caelestia.url = "github:anarion80/caelestia-shell?ref=topbar";
};

And then add the necessary packages:

{
  pkgs,
  inputs,
  ...
}: {
  environment.systemPackages = [
    inputs.caelestia.packages.${pkgs.stdenv.hostPlatform.system}.default
    inputs.caelestia.inputs.caelestia-cli.packages.${pkgs.stdenv.hostPlatform.system}.default
    pkgs.app2unit
    pkgs.extractmonopcm
    pkgs.converttopcm
  ];
}

Issues

Initially I struggled with screen flickering, no audio, Bluetooth keyboard connectivity issues, screenshots, screen sharing, etc., but eventually I was able to resolve most if not all of them.

Screen issues were fixed first by using open-source NVIDIA beta drivers and I think were simply fixed in later versions:

    hardware.nvidia = {
      modesetting.enable = true;
      powerManagement.enable = false;
      powerManagement.finegrained = false;
      nvidiaPersistenced = false;
      open = true;
      nvidiaSettings = true;
      package = config.boot.kernelPackages.nvidiaPackages.beta;
    };

I could not connect my Kinesis Bluetooth keyboard to the system. The whole Bluetooth controller was not even getting detected or visible, so there was no way to discover and pair the keyboard.

After some searching I tried disabling and then enabling wireless services:

rfkill block bluetooth
rfkill unblock bluetooth
bluetoothctl discoverable on
bluetoothctl pairable on

And that was it - the controller appeared and the keyboard saw it and paired with it. Once or twice since then due to some unknown reason the keyboard did not connect again I had to apply the rfkill commands again.

Screen sharing was temporarily solved by downgrading bitdepth in Hyprland and is now fixed.

Secrets Management

When using flakes, the whole config needs to be added to git, and it gets copied to the nix store, so you can’t have any sensitive information unencrypted in the repo config and managing secrets becomes mandatory.

I decided to use sops-nix for secrets management, as it was often recommended for NixOS. Installation was straightforward, generating age encryption keys and creating the encrypted system.yaml file as well.

I have my sops-encrypted secrets stored in a private repo, which is then an input in my flake.

Where I struggled for a while was with home-manager use of sops-nix. home-manager has only a subset of features provided by the system-wide sops-nix and the secrets end up in a different location - under $HOME. So you have to be mindful of where the particular secret is going to be used, in what scope, by what user/service, and then separate them accordingly between system and home-manager.

Another difficult aspect was even importing the sops-nix into home-manager modules. Dustin Lyons’ original config was using agenix for secrets rather than sops-nix and its layout was not clear enough to inject sops-nix into it. I had to redo the whole config, make it more modularized and separate home-manager enough, so that it finally clicked for me and I knew where to import the module. In the end, this is the relevant piece of my nixosConfigurations:

        nixpkgs.lib.nixosSystem {
          system = cleanSystem;
          specialArgs = {
            inherit inputs localSecrets flakePath user;
            inherit hostName;
          };
          modules = [
            ./modules/home-manager/module.nix
            home-manager.nixosModules.home-manager
            sops-nix.nixosModules.sops
            disko.nixosModules.disko
            ({
              config,
              pkgs,
              lib,
              ...
            }: {
              home-manager = {
                sharedModules = [inputs.sops-nix.homeManagerModules.sops];
                useGlobalPkgs = true;
                useUserPackages = true;
                extraSpecialArgs = {inherit inputs localSecrets;};
                users.${user} = import ./modules/home-manager {
                  inherit config pkgs lib inputs localSecrets;
                  profile = config.modules.home-manager.profile;
                  extraConfig = config.modules.home-manager.extraConfig;
                  extraPackages = config.modules.home-manager.extraPackages;
                  excludePackages = config.modules.home-manager.excludePackages;
                };
              };
            })
            (hostsDir + "/${hostName}/default.nix")
          ];
        };

I use secrets for SSH keys, passwords, email addresses, API keys, CIFS mounts credentials, etc. Especially this last part is very useful for me, because I have all the many CIFS/SMB mounts from different servers mounted automatically with credentials encrypted. It took a while to arrive at a working solution, and Qwen was helpful in doing the legwork.

Ultimately, I have only mount passwords encrypted in sops:

mounts:
    mount1: password1
    mount2: password2

While all other data is in the module itself:

mountsConfig = {
    # Define all your mounts here with their non-sensitive parameters
    "server1_mount1" = {
        username = "anarion-nas";
        local_path = "/mnt/server1/mount1";
        remote_path = "server1/mount1";
    };
    "server2_mount1" = {
        username = "anarion-nas";
        local_path = "/mnt/server2/mount1";
        remote_path = "server2/mount1";
    };
    "server3" = {
        username = "admin";
        local_path = "/mnt/server3";
        remote_path = "server/admin/download";
        vers = "1.0";
        mount_user = "anarion-nas";
    };
};

Then I use sops-nix templates to create credential files for all the mounts.

This is the resulting module, which also takes care of creating the mount directories and fileSystems configurations:

{
  config,
  lib,
  pkgs,
  ...
}: let
  # Helper function to get user ID from username
  getUserId = username: let
    userConfig = config.users.users.${username} or null;
  in
    if userConfig != null
    then toString userConfig.uid
    else "1000"; # fallback to 1000

  # Helper function to get group ID from username
  getGroupId = username: let
    groupConfig = config.users.groups.${username} or null;
  in
    if groupConfig != null
    then toString groupConfig.gid
    else "1000"; # fallback to 1000

  # Generate filesystem configurations for each mount
  generateFileSystems = mounts:
    lib.mapAttrs' (mountName: mountConfig: let
      # Use permissions from config or default to 775
      fileMode = mountConfig.permissions or "0775";
      dirMode = mountConfig.permissions or "0775";
      vers = mountConfig.vers or "2.0";
      # Use mount_user for uid/gid if specified, otherwise fallback to username
      mountUser = mountConfig.mount_user or mountConfig.username;
    in {
      name = mountConfig.local_path;
      value = {
        device = "//${mountConfig.remote_path}";
        fsType = "cifs";
        options = [
          # Create a credentials file for this specific mount
          "credentials=/run/mount-credentials/${mountName}"
          "uid=${getUserId mountUser}"
          "gid=${getGroupId mountUser}"
          "username=${mountConfig.username}"
          "vers=${vers}"
          "file_mode=${fileMode}"
          "dir_mode=${dirMode}"
          "nounix"
          "nofail"
          "x-systemd.idle-timeout=60,x-systemd.device-timeout=5s,x-systemd.mount-timeout=5s"
        ];
        depends = ["/run/mount-credentials/${mountName}"];
      };
    })
    mounts;

  # Generate activation script to create mount directories
  generateMountDirs = mounts: let
    mkdirCommands =
      lib.mapAttrsToList (mountName: mountConfig: let
        # Use permissions from config or default to 775
        permissions = mountConfig.permissions or "775";
        # Use mount_user for ownership if specified, otherwise fallback to username
        owner = mountConfig.mount_user or mountConfig.username;
      in ''
        mkdir -p ${mountConfig.local_path}
        chown ${owner}:${owner} ${mountConfig.local_path}
        chmod ${toString permissions} ${mountConfig.local_path}
      '')
      mounts;
  in
    lib.concatStringsSep "
" mkdirCommands;

  # Define the mounts configuration structure
  mountsConfig = {
    # Define all your mounts here with their non-sensitive parameters
    "server1_mount1" = {
      username = "anarion-nas";
      local_path = "/mnt/server1/mount1";
      remote_path = "server1/mount1";
    };
    "server2_mount1" = {
      username = "anarion-nas";
      local_path = "/mnt/server2/mount1";
      remote_path = "server2/mount1";
    };
    "server3" = {
      username = "admin";
      local_path = "/mnt/server3";
      remote_path = "server/admin/download";
      vers = "1.0";
      mount_user = "anarion-nas";
    };
  };
in {
  # Create credential files
  sops.templates =
    lib.mapAttrs' (mountName: mountConfig: {
      name = "cifs-${mountName}-credentials";
      value = {
        path = "/run/mount-credentials/${mountName}";
        mode = "0600";
        content = ''
          username=${mountConfig.username}
          password=${config.sops.placeholder."mounts/${mountName}"}
        '';
      };
    })
    mountsConfig;

  # Generate filesystem configurations
  fileSystems = generateFileSystems mountsConfig;

  # Create activation script to ensure mount directories exist
  system.activationScripts.createMountDirs = {
    text = generateMountDirs mountsConfig;
    deps = ["var"];
  };
}

localSecrets = builtins.fromJSON (builtins.readFile "${self}/local_secrets.json");

  accounts.email.accounts = {
      ${localSecrets.email_accounts."1".address} = {
        primary = true;
        flavor = "gmail.com";

        realName = localSecrets.email_accounts."1".realName;
        signature = {
          showSignature = "none";
          text = ''
            ${localSecrets.email_accounts."1".realName}
          '';
        };

{
  "email_accounts": {
    "1": {
      "address": "[email protected]",
      "realName": "Real Name"
    }
  }
}

Multiple Hosts

Dustin Lyons’ original config provides one host per platform, so when I wanted to add a NixOS config for another host - my laptop - I had to update the config. I wanted it to be somewhat automated, so that I would only add a new host config under the hosts/nixos folder, and then it would be automatically included in nixosConfigurations, with no need to update the main flake.nix file. An optional systemFile under a particular host would determine the system (x86_64-linux, etc.).

With that, I have a mkHostConfig function that maps over all the valid hosts from the folder and creates a config for them:

nixosConfigurations = let
      # Get all directories in the hosts directory
      hostsDir = ./hosts/nixos;
      hostDirs = builtins.attrNames (builtins.readDir hostsDir);

      # Filter out files (only keep directories) and non-nixos directories if needed
      isDirectory = name: let
        path = hostsDir + "/${name}";
      in
        builtins.pathExists (path + "/default.nix");

      validHosts = builtins.filter isDirectory hostDirs;

      # Create a configuration for each host
      mkHostConfig = hostName: let
        # Check if host has a specific system architecture defined
        systemFile = hostsDir + "/${hostName}/system";
        hostSystem =
          if builtins.pathExists systemFile
          then builtins.readFile systemFile
          else "x86_64-linux";
        # Remove any trailing whitespace/newlines
        cleanSystem = builtins.replaceStrings ["\n" " "] ["" ""] hostSystem;
      in
        nixpkgs.lib.nixosSystem {
          system = cleanSystem;
          specialArgs = {
            inherit inputs localSecrets flakePath user;
            inherit hostName;
          };
          modules = [
            ./modules/home-manager/module.nix
            home-manager.nixosModules.home-manager
            sops-nix.nixosModules.sops
            disko.nixosModules.disko
            ({
              config,
              pkgs,
              lib,
              ...
            }: {
              home-manager = {
                sharedModules = [inputs.sops-nix.homeManagerModules.sops];
                useGlobalPkgs = true;
                useUserPackages = true;
                extraSpecialArgs = {inherit inputs localSecrets;};
                users.${user} = import ./modules/home-manager {
                  inherit config pkgs lib inputs localSecrets;
                  profile = config.modules.home-manager.profile;
                  extraConfig = config.modules.home-manager.extraConfig;
                  extraPackages = config.modules.home-manager.extraPackages;
                  excludePackages = config.modules.home-manager.excludePackages;
                };
              };
            })
            (hostsDir + "/${hostName}/default.nix")
          ];
        };

      # Create attribute set of host configurations for x86_64-linux only
      hostConfigs = builtins.listToAttrs (
        builtins.map (name: {
          inherit name;
          value = mkHostConfig name;
        })
        validHosts
      );
    in
      hostConfigs;
  };

Stable vs. Unstable

When using NixOS and nix packages you can use them from the official stable and unstable channels. Stable has less frequent updates and less breakage; unstable is the bleeding edge. I initially selected the unstable:

inputs = {
    nixpkgs.url = "github:nixos/nixpkgs/nixos-unstable";
    home-manager = {
      url = "github:nix-community/home-manager";
      inputs.nixpkgs.follows = "nixpkgs";
    };
};

And it has been surprisingly stable. I usually refresh and update my config (nix flake update) every few weeks or when I need some updated package. After adding more and more packages, though, it more often happens that one package is failing to build and I need to wait a couple of days until it is fixed. Then perhaps some other package is broken, so the time before I can upgrade is even longer.

Whenever I’m blocked, I look for an existing issue in the nixpkgs repo and I subscribe to it. Sooner or later there will be a PR with a fix, so I subscribe to that one too. When that PR is merged, I keep checking the molybdenum software nixpkgs PR tracker with the PR number - when it shows the merge to nixpkgs-unstable branch is done, I can retry the build and activation.

Another related topic is the time it takes to build and switch. Even though I use the binary cache, certain packages need to be compiled and the whole process can take 1-2 hours on my system. It’s not a big deal for me, but one needs to be aware.
